Steel Truck Wheels
| HEAVY DUAL TRUCK WHEELS | |||||
| SIZE | MAX LOAD (LBS) | FINISH/COLOR | BOLT PATTERN | CENTER BORE | OFFSET |
| 16 X 6 | 3500 | SILVER | 8 ON 6.50 | 4.75" | 5.5" |
| 16 X 6 | 3500 | SILVER | 8 ON 6.50 | 4.88" | 5.5‘ |
| SIZE | MAX LOAD (LBS) | FINISH/COLOR | BOLT PATTERN | CENTER BORE | OFFSET |
| 17.5x6.75 | 6005 | SILVER | 8 ON 6.50 | 4.75“ | - |
| 17.5x6.75 | 6005 | SILVER | 8 ON 6.50 | 4.75” | -0.19“ |
| 17.5x6.75 | 6005 | SILVER | 8 ON 6.50 | 4.75“ | 0.31” |
| 17.5x6.75 | 6005 | SILVER | 8 ON 6.50 | 4.75” | 0.5“ |
| HUB PILOT DISC WHEELS | |||||
| Size | Hand Holes | CBD(mm) | PCD(mm) | Offset | Load Lbs/PSI |
| 17.5X6.75 | 4 | 220 | 8x275 | 5.6" | 6200/125 |
| 22.5X8.25 | 2&5&10 | 220 | 10x285.75 | 6.62" | 7400/120 & 8000/120 |
| 24.5x8.25 | 2&5&10 | 220 | 10x285.75 | 6.62" | 7400/120 & 8000/120 |
| STUD PILOT DISC WHEEL | |||||
| Size | Hand Holes | CBD(mm) | PCD(mm) | Offset | Load Lbs/PSI |
| 22.5X8.25 | 2 | 221 | 10x285.75 | 6.62" | 7400/120 & 8000/120 |
| 24.5x8.25 | 2 | 221 | 10x285.75 | 6.62" | 7400/120 & 8000/120 |
| TUBELESS DEMOUNTABLE RIMS | |||||
| Size | Offset | Load Lbs/PSI | |||
| 22.5X8.25 | 4.75" | 7400/120 | |||
| 24.5x8.25 | 4.75" | 7400/120 | |||
